Anatomy Atlases: Atlas of Human Anatomy in Cross Section: Section 1. Head and Neck

Atlas of Human Anatomy in Cross Section: Section 1. Head and Neck

Plate 1.12

Ronald A. Bergman, Ph.D., Adel K. Afifi, M.D., Jean J. Jew, M.D., and Paul C. Reimann, B.S.
Peer Review Status: Externally Peer Reviewed


Plate 1.12

Upper Left Quadrant

Lower Left Quadrant

Lower Right Quadrant

Upper Right Quadrant

1. Lamina terminalis
2. Frontal bone
3. Frontal (anterior) horn of lateral ventricle
4. Head of caudate nucleus
5. Anterior commissure
6. External capsule
7. Anterior perforated substance
8. Claustrum
9. Substontio nigra
10. Temporal bone

11. Fimbria of Fornix
12. Hippocampus
13. Posterior cerebral a.
14. Ambient cistern
15. Tentorium cerebelli
16. Superior colliculus
17. Occipital bone
18. Aqueduct of Sylvius
19. Internal occipital crest

20. Vermis of cerebellum
21. Cerebellar hemisphere
22. Superior cerebellar a.
23. Parahippocampal gyrus
24. Auricle
25. Temporal lobe white matter
26. Temporal (inferior) horn of lateral ventricle
27. Alveus

28. Middle temporal gyrus
29. Superior temporal gyrus
30. Cerebral peduncle
31. Extreme capsule
32. Insula cortex (island of Reil)
33. Putamen
34. Posterior communicating a.
35. Anterior limb of internal capsule
36. Oculomotor nerve
37. Frontal lobe white matter
38. Basilar a.
39. Anterior cerebral a

This is a section (looking down) through the basal ganglia, midbrain, and cerebellum. In the interhemispheric fissure rostrally is the anterior cerebral artery (39). On each side of the interhemispheric fissure are the frontal lobes (37). The floor of the frontal (anterior) horn of the lateral ventricle (3) is seen. The lateral ventricles on both sides are seen for the last time. The head of the caudate nucleus (4) lines the lateral wall of the frontal (anterior) horn of the lateral ventricle (3). The anterior limb of the internal capsule (35) separates the head of the caudate nucleus (4) from the putamen (33). The anterior commissure (5) is in close proximity to the putamen (33). Caudal to the anterior commissure (5) is the anterior perforated substance (7). Caudal to the interhemispheric fissure and in close proximity to the anterior commissure (5) is the lamina terminalis (1), landmark for the most rostral part of the embryonic neural tube. Lateral to the putamen (33) is the external capsule (6). The claustrum (8) is sandwiched between the external (6) and extreme (31) capsules. The midbrain is seen rostral to the cerebellum (20,21). Within the midbrain, the following structures are seen: aqueduct of Sylvius (18), superior colliculus (16), substantia nigra (9), and cerebral peduncle (30). The oculomotor nerve (36) is seen exiting from the inferior surface of the midbrain. In the subarachnoid space around the midbrain, the following arteries are seen: basilar (38), posterior communicating (34), posterior cerebral (13), and superior cerebellar (22). The ambient cistern (14) is seen in relation to the midbrain. Caudal to the midbrain is the cerebellum with its midline vermis (20) and lateral hemispheres (21). The tentorium cerebelli (15) is a dural fold between the cerebellum and occipital lobe. Caudal to the cerebellum is the occipital bone (17) and internal occipital crest (19). The temporal (inferior) horn of the lateral ventricle (26) makes its last appearance. The hippocampus (12) protrudes into the temporal (inferior) horn of the lateral ventricle (26). The alveus (27), an outflow tract from the hippocampus, is continuous with the fimbria of the fornix (11). The hippocampus (12) is seen as an invagination of the parahippocampal gyrus (23) into the temporal (inferior) horn of the lateral ventricle (26). The insula (island of Reil) (32) is seen in the depth of the lateral (sylvian) fissure. In the temporal lobe (25), the superior (29) and middle (28) temporal gyri are seen. The frontal (2), temporal (10), and occipital (17) bones and the auricle (24) are seen.
