Anatomy Atlases: Atlas of Human Anatomy in Cross Section: Section 7. Lower Limb

Atlas of Human Anatomy in Cross Section: Section 7. Lower Limb

Plate 7.39

Ronald A. Bergman, Ph.D., Adel K. Afifi, M.D., Jean J. Jew, M.D., and Paul C. Reimann, B.S.
Peer Review Status: Externally Peer Reviewed


Plate 7.39

Upper Left Quadrant

Lower Left Quadrant

Lower Right Quadrant

Upper Right Quadrant

1. Second digit, distal phalanx
2. Second digit, middle phalanx
3. Second digit, proximal phalanx
4. Second metatarsal
5. Lumbrical and interosseous mm.
6. First digit, distal phalanx
7. First digit, proximal phalanx
8. First metatarsal head
9. Tendon m. abductor hallucis

10. Tendons mm. flexor digitorum longus
11. Tendon m. flexor hallucis longus
12. Plantar aponeurosis

13. Calcaneus, tuberosity
14. Quadratus plantae m.
15. Abductor digiti quinti m.
16. Fifth metatarsal

17. Fourth metatarsal
18. Interphalangeal joint and fourth digit, proximal phalanx
19. Fourth digit, middle phalanx
20. Third metatarsal
21. Third digit, proximal phalanx
22. Third digit, middle phalanx
23. Third digit, distal phalanx

This section passes through the tuberosity of the calcaneus (13); the first (8), second (4), third (20), fourth (17), and fifth (16) metatarsals; the proximal phalanx of the first (7), second (3), third (2 1), and fourth (18) digits; and the distal phalanx of the first (6), second (1), and third (23) digits.
