Anatomy Atlases: Atlas of Human Anatomy in Cross Section: Section 4. Upper Limb

Atlas of Human Anatomy in Cross Section

Section 4. Upper Limb

Ronald A. Bergman, Ph.D., Adel K. Afifi, M.D., Jean J. Jew, M.D., and Paul C. Reimann, B.S.
Peer Review Status: Externally Peer Reviewed


Key Figure 4

Key Figure 4

1. Acromion of scapula
2. Clavicle
3. Coracoid process of scapula
4. Glenoid process of humerus
5. Humeral head
6. Lesser tubercle of humerus
7. Intertubercular groove
8. Greater tubercle of humerus
9. Scapula
10. Medial border of scapula
11. Lateral border of scapula
12. Deltoid m.
13. Pectoralis major m.
14. Deltoid tuberosity of humerus
15. Inferior angle of scapula
16. Coracobrachialis m.
17. Humerus
18. Triceps (long head) m.
19. Biceps brachii m.
20. Brachialis m.
21. Pronator teres m.
22. Medial supracondylar ridge of humerus
23. Lateral supracondylar ridge of humerus
24. Medial epicondyle of humerus
25. Capitulum of humerus
26. Trochlea of humerus
27. Radial head
28. Coronoid process
29. Bicipital aponeurosis
30. Radial tuberosity
31. Pronator teres m.
32. Brachioradialis m.
33. Flexor carpi radialis m.
34. Ulna
35. Palmaris longus m.
36. Radius
37. Flexor carpi ulnaris m.
38. Flexor digitorum superficialis m.
39. Ulnar head
40. Radius, styloid process
41. Flexor retinaculum
42. Carpal bones
43. Thenar mm.
44. Palmar aponeurosis
45. Hypothenar mm.
46. Metacarpal, 5
47. Phalanx, proximal
48. Phalanx, proximal
49. Phalanx, distal
50. Phalanx, middle
51. Phalanx, distal

Lower Arm Plates

4.1
4.2
4.3
4.4
4.5
4.6

Elbow Plates

4.7
4.8
4.9
4.10

Forearm Plates

4.11
4.12
4.13
4.14
4.15
4.16
4.17
4.18
4.19
4.20
4.21
4.22
4.23
4.24
4.25

Wrist and Hand Plates

4.26
4.27
4.28
4.29
4.30
4.31
4.32
4.33
4.34
4.35
4.36
4.37
4.38
4.39
4.40
